Product ES fisheye p2p wifi ip cameras

Models EC2-G6

Technical Parameter

CPU GM8135S OV9712

Website s.360eye.cc

Sensor : 1/4Progressive Scan CMOS

Lens : 1.44mm185 fisheye lens

Angle Horizontal185

Video format 1280*7201MP)

Video Compression Standard H.264

Audio Compression Standard G.711

Video Frame Rate Max 25 fps

Video Play back Mode Mobilphone APP

Aduio Input / Output Input Built in Microphone Output Built in horn

IR Night Vision IR LEDs,IR distance10m Optional IR-CUT automatic switching

Focus Mode Manaul

Local Storage TF/SD Card , Max support 128GB

Multi Protocols TCP/UDPIPSMTPFTPDHCPUPNPNTP

Wifi IEEE802.11b/g/n

Image Rotation Mirror / inverted

Video monitor support

Motion Detection support

Alarm Actions App push the snapshot

User Setting Administrator, visitors

System Interface 1pc USB interface , 1pc TF(Micro SD )card interface

Power 5V 1A

Power Consumption <5W

Operating Temperature 0'C~60'C

size:4*3.7*11cm

Packing size15.2*10.1*4.1cm

N.W.:72g

G.W.:176g
