Nodal Ninja 6 E2 Mecha with Nadir Adapter - Automatic Robotic Panoramic Head

Nodal Ninja 6 E2 Mecha with Nadir Adapter - Automatic Robotic Panoramic Head

$ 66.08

$ 85.90

Save: $

Title:
  • DefaultTitle
Unavailable
Please select combo product attributes
The combo subtotal is $,SAVE$

Product Details

Dual axis pan tilt 360/VR panoramic head solution from Nodal Ninja / Fanotec with full automation of both axis. Design based on NN6 with Nadir Adapter, with 2 Mecha E2 Rotators and 2 C1 Controllers which are wirelessly linked together. Mecha motors are lightweight, quiet and power efficient.

This bundle can be used as a single-axis horizontal rotator for single row shooting or you can use a dual-axis rotator for both horizontal and vertical movements. The Mecha E2 and C1 is modular in design, paving the way for future low-cost upgrade paths. You can shoot 360° panoramas or even high-resolution gigapixel images with this bundle. Includes Nadir Adapter for easier capture of the area below tripod to make the tripod disappear from a 360 photo.

For supported loads take a look at the attached specs (in the image).

Mecha E2 Rotator Features
  • Lower rotator supports 4kg, including panoramic head, strong enough for dual camera stereo setups
  • Upper rotator supports weights as per specifications image, don't forget to count both camera and lens
  • Compact and light weight for the load rating
  • Weight 645g
  • Dimensions 126 x 48 x 51 mm
Mecha Single Axis Controller C1 Features:
  • Supports one Mecha rotator.
  • Compact controller with built in battery and charger.
  • Two NCR18650GA 7.2v 3300mAh high capacity batteries.
  • WIFI remote control for smartphones, tablets, PCs by using simple web page interface.
  • Supports linking and controlling multiple controllers via WIFI, connection via a wifi access point, over the air firmware upgrade and remote control over the internet.
  • 3 buttons to run presets stored in the memory, which can be configured via the web page inteface.
  • 5 LEDs to indicate the remaing battery capacity.
  • CAM port with opto-isolated trigger for focus and shutter release.
  • Multipurpose AUX port (to be implemented with future firmware upgrade) for shutter confirmation, Radio Frequency Start/Stop remote trigger, wired Start/Stop trigger or IR remote emitter etc.

Important: Long Remote Shutter Release Cable (not included)

The cable ensures camera triggering and focus lock. Any camera supporting a wired remote shutter release cable is compatible with MECHA. The CAM port on the Mecha is compatible with many 2.5mm 3rd party stereo remote shutter cords. You can use your own cable or purchase a cable from us here. A longer cable is recommended for the dual axis application to ensure the cable does not get tangled.


Includes:
  • 2x Nodal Ninja Mecha E2 Rotator
  • 2x Nodal Ninja Mecha C1 Controller
  • NN6 rails (vertical, horizontal, upper; assembled)
  • NN6 nadir adapter
  • NN6 camera plate
  • Case
  • Misc.

Weight: 2.4kg (of the entire kit - without case and without spare parts)

Maximum load: This setup supports a camera/lens up to 3.0 kg (6.6 lb) and NPP up to 145mm from the pivot point making it ideal for mirror-less, and full size DSLR cameras. Shoot 360° panoramas or even high-resolution gigapixel images.
Max height: of lens axis from camera base supported is 76.5mm.

This kit is a fully functional robotized Nodal Ninja 6 E2. No other parts needed.
